COME AND STEP INTO THE MERCURY WORLD...



Mercury yanında...

Dünyadan daha önce.

    Onlarca yıldır tekneci odaklı yenilikçi anlayışla güvenilir teknoloji üretilen, sezgisel ürünlerin, sonsuz fırsatların ve mükemmele sahip olma tecrübesini sağlamak için çalışan nitelikli ve kendini adamış küresel ölçekli bir destek ekibinin yer aldığı Mercury Marine® dünyasına hoşgeldiniz. Motorunuza ve onu  üretip geliştiren ekibe güvenle yeni ufuklar keşfetmeye hazır olun.



3.5 - 6 HP FourStroke

Bu beygir gücündeki dıştan takmalı motorlar için taşınabilirlik temel özelliktir ve Mercury 3.5 - 6 HP dört zamanlı motorlar, bu sınıftaki en hafif dıştan takmalı motorlar arasındadır. Bununla birlikte, bu motorların tüm öyküsü sadece hafif ve uygun fiyatlı olmaları değildir. Her taşınabilir Mercury FourStroke, otomatik geri vites kilit sistemimiz ve kullanışlı tümleşik yakıt depolarımız gibi zengin özelliklerle doludur. Bu FourStroke'lar, daha yüksek beygir gücüne sahip ürünlerimizde kullandığımız aynı korozyona dayanıklılık işlemlerine tabi tutulmaktadır. Kaliteli üretim son derece eğitimli geniş bayi ağıyla, bayi destek sistemleri ile ve sektörün en iyisi olan yedek parça tedarik zinciriyle desteklenmektedir. Dünya genelinde tüm teknecilerin taşınabilir FourStroke'larımıza güvenmesi boşuna değil...

Hafif siklet şampiyonlar

Özellikler

3,5 HP

5 HP

6 HP

HP / kW

  • 3.5 / 2.6

Engine type

  • 1 cylinder

Displacement (CID/CC)

  • 5.2 / 85

Full throttle RPM

  • 5000-6000

Fuel induction system

  • 2-valve pushrod (overhead valve)

Recommended fuel

  • 87% octane / up to 10% ethanol

Recommended oil

  • Mercury FourStroke Oil 10W-30

Engine protection operator warning system

  • Over-rev

Starting

  • Manual

Steering

  • Tiller with 360° turning

Shaft length

  • 15" / 381 mm

  • 20" / 508 mm

Gearcase ratio

  • 2.15:1

Dry weight *Lightest model available

  • 41 lbs / 18 kg

CARB star rating

  • 3

Bore and stroke

  • 2.16 x 1.42" / 55 x 36 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Carbureted

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N

Gearcase options

  • Standard

Trim system

  • 4 position

Trim positions

  • 4

Exhaust system

  • Above prop

Shallow water trim range (degrees)

  • 16

Integrated fuel tank (gal / L)

  • 0.3 / 1.1

Color

  • Phantom Black

HP / kW

  • 5 / 3.7

Engine type

  • 1 cylinder

Displacement (CID/CC)

  • 7.5 / 123

Full throttle RPM

  • 4500-5500

Fuel induction system

  • 2-valve pushrod (overhead valve)

Recommended fuel

  • 87% octane / up to 10% ethanol

Recommended oil

  • Mercury FourStroke Oil 10W-30

Engine protection operator warning system

  • Low oil pressure

  • Over-rev

Starting

  • Manual

Steering

  • Tiller

Shaft length

  • 15" / 381 mm

  • 25" / 635 mm

Gearcase ratio

  • 2.15:1

Dry weight *Lightest model available

  • 57 lbs / 26 kg

CARB star rating

  • 3

Bore and stroke

  • 2.32 x 1.77" / 59 x 45 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Carbureted

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim positions

  • 6

Exhaust system

  • Through prop

Shallow water drive

  • Yes

Shallow water trim range (degrees)

  • 16

Integrated fuel tank (gal / L)

  • 0.3 / 1.1

Optional fuel tank (gal / L)

  • 3.2 / 12

Color

  • Phantom Black

HP / kW

  • 6 / 4.4

Engine type

  • 1 cylinder

Displacement (CID/CC)

  • 7.5 / 123

Full throttle RPM

  • 5000-6000

Fuel induction system

  • 2-valve pushrod (overhead valve)

Recommended fuel

  • 87% octane / up to 10% ethanol

Recommended oil

  • Mercury FourStroke Oil 10W-30

Engine protection operator warning system

  • Low oil pressure

  • Over-rev

Starting

  • Manual

Steering

  • Tiller

Shaft length

  • 15" / 381 mm

  • 20" / 508 mm

Gearcase ratio

  • 2.15:1

Dry weight *Lightest model available

  • 57 lbs / 26 kg

CARB star rating

  • 3

Bore and stroke

  • 2.32 x 1.77" / 59 x 45 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Carbureted

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim positions

  • 6

Exhaust system

  • Through prop

Shallow water drive

  • Yes

Shallow water trim range (degrees)

  • 16

Integrated fuel tank (gal / L)

  • 0.3 / 1.1

Optional fuel tank (gal / L)

  • 3.2 / 12

Color

  • Phantom Black



9.9 HP FourStroke

Ağırlıkta hafif.

  Özelliklerde ağır.

Mercury 9.9 FourStroke'lar hala kendi sınıfının en hafifidir, fakat ağırlıkta hafiflik işin kolayına kaçmak demek değildir... 9.9 FourStroke'larımız, tek elle kolay vites değiştirme sağlayan kullanışlı çok fonksiyonlu bir yeke koluna sahiptir ve manüel jikle ve ana özellikler fonksiyonların başlatılmasını kolaylaştırır. Ayrıca, bu dıştan takmalı motorlargeriye doğru giderken motoru yerinde tutmak için elinizle kullanışsız bir kolu değiştirmenizi gerektirmeyen özel otomatik ters çevirme kancaları ile donatılmış olarak gelir.

9 HP

9 HP CT

HP / kW

  • 9.9 / 7.3

Engine type

  • Inline 2

Displacement (CID/CC)

  • 12.8 / 208

Full throttle RPM

  • 5000-6000

Fuel induction system

  • 2 valves per cylinder, single overhead cam (SOHC)

Alternator amp / Watt

  • 6 amp / 76 watt

Recommended fuel

  • 87% octane / up to 10% ethanol

Recommended oil

  • Mercury FourStroke Oil 10W-30

Engine protection operator warning system

  • Low oil pressure

  • Over-rev

Starting

  • Electric

  • Manual

Steering

  • Remote

  • Tiller

Shaft length

  • 15" / 381 mm

  • 20" / 508 mm

Gearcase ratio

  • 2.08:1

Dry weight *Lightest model available

  • 84 lbs / 38 kg

CARB star rating

  • 3

Bore and stroke

  • 2.16 x 1.73" / 55 x 44 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Carbureted

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim positions

  • Ratcheting

Exhaust system

  • Through prop

Shallow water drive

  • Yes

Shallow water trim range (degrees)

  • 16

Remote fuel tank standard (gal / L)

  • 3.2 / 12

Color

  • Phantom Black

Daha fazla itiş gücü

Mercury Command Thrust motorlarında daha derin bir vites kutusu ve dört kanatlı, yüksek itişli pervaneler ile, bunlara uyumlu vites oranı-trolling ve her durumda tam kontrol için mükemmel yapı- bulunur.



15 - 20 HP FourStroke

Kendi Sınıfının Zirvesinde.

      Dıştan takma motor sınıfına bağlı olan tekneciler, sadece olağanüstü iyi performansa sahip olmakla kalmayıp aynı zamanda zengin özelliklere de sahip olan güvenilir bir motor istemektedirler. Mercury 15 - 20 hp FourStroke'lar sizi asla hayal kırıklığına uğratmaz. Bu yüksek silindir hacimli dıştan takma motorlar hafif tasarımlara, çift su yoluna, gücü ve kontrolü parmak uçlarınızın  kumandasına sunan zengin özellikli ve çok fonksiyonlu bir eke koluna sahiptir. Bu Mercury FourStrok'lardan birini denedikten sonra neden kendi sınıfımızın zirvesinde olduğumuzu anlayacaksınız.

15 HP

20 HP

HP / kW

  • 15 / 11.1

Engine type

  • Inline 2

Displacement (CID/CC)

  • 20.3 / 333

Full throttle RPM

  • 5700 - 6200

Fuel induction system

  • 2 valves per cylinder, single overhead cam (SOHC)

Alternator amp / Watt

  • 12/145 electric

Recommended fuel

  • 87% octane / up to 10% ethanol

Recommended oil

  • 25W-40 Synthetic Blend

  • Mercury FC-W 10W-30 4-Stroke Marine Oil

Engine protection operator warning system

  • Low oil pressure

  • Over-rev

  • Overheat

  • Sensor failure

Starting

  • Electric

  • Manual

Steering

  • Remote

  • Tiller

Shaft length

  • 15" / 381 mm

  • 20" / 508 mm

Gearcase ratio

  • 2.15:1

Dry weight *Lightest model available

  • 99 lbs / 45 kg

CARB star rating

  • 3

Bore and stroke

  • 2.40 x 2.24" / 61 x 57 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim system

  • Manual

  • Power Tilt

Trim positions

  • 6

Exhaust system

  • Through prop

Shallow water drive

  • Yes

Shallow water trim range (degrees)

  • 16

Remote fuel tank (optional)

  • Yes

Remote fuel tank standard (gal / L)

  • 6.6 / 25

Color

  • Phantom Black

HP / kW

  • 20 / 14.7

Engine type

  • Inline 2

Displacement (CID/CC)

  • 20.3 / 333

Full throttle RPM

  • 5700 - 6200

Fuel induction system

  • Single Overhead Cam

Alternator amp / Watt

  • 12/145 electric

Recommended fuel

  • 87% octane / up to 10% ethanol

Recommended oil

  • 25W-40 Synthetic Blend

  • Mercury FC-W 10W-30 4-Stroke Marine Oil

Engine protection operator warning system

  • Low oil pressure

  • Over-rev

  • Overheat

  • Sensor failure

Starting

  • Electric

  • Manual

Steering

  • Remote

  • Tiller

Shaft length

  • 15" / 381 mm

  • 20" / 508 mm

Gearcase ratio

  • 2.15:1

Dry weight *Lightest model available

  • 99 lbs / 45 kg

CARB star rating

  • 3

Bore and stroke

  • 2.40 x 2.24" / 61 x 57 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim system

  • Manual

  • Power Tilt

Trim positions

  • 6

Exhaust system

  • Through prop

Shallow water drive

  • Yes

Shallow water trim range (degrees)

  • 16

Remote fuel tank (optional)

  • Yes

Remote fuel tank standard (gal / L)

  • 6.6 / 25

Color

  • Phantom Black



25 - 30 HP FourStroke

Siz Söylediğinizde Çalışır.

    25 - 30 hp FourStroke'ların beygir gücü küçük olabilir, fakat silindir hacimleri büyüktür. Alt uç torku güçlü yüklere sahip olan bu dıştan takmalı motorlar, ani gaz kelebeği yanıtı ve hızlı ivmelenme ile ihtiyacınız olan güce sahiptir. Bu modellerde standart bulunan çok fonksiyonlu yeke tutacağı sayesinde, tek elinizi kullanarak bile denize açılabilirsiniz. Bu devrim niteliğindeki all-in-one tasarım, manevra yapmak, durmak, gaz konrolü, yana eğilmek, sürtünme kontrolü ve dümen kontrolü için tek elden kontrol imkanı sağlıyor. 25-30 hp modeli kolay muhafaza sağlamak için her yöne katlanabilen bir yeke ile kullanışlı olarak tasarlanmıştır.

25 HP

HP / kW

  • 25 / 18.4

Engine type

  • Inline 3

Displacement (CID/CC)

  • 32.1 / 526

Full throttle RPM

  • 5250-6250

Fuel induction system

  • 2 valves per cylinder, single overhead cam (SOHC)

Alternator amp / Watt

  • 15 amp / 186 watt

Recommended fuel

  • Unleaded 90RON minimum

Recommended oil

  • Mercury FourStroke Oil 10W-30

Engine protection operator warning system

  • Low oil pressure

  • Over-rev

  • Overheat

  • Sensor failure

Starting

  • Electric (turn-key)

  • Manual

Steering

  • Remote

  • Tiller

Shaft length

  • 15" / 381 mm

  • 20" / 508 mm

Gearcase ratio

  • 1.92:1

Dry weight *Lightest model available

  • 78 kg

CARB star rating

  • 3

Bore and stroke

  • 2.40 x 2.36" / 61 x 60 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim system

  • Gas assist

  • Power Trim

Exhaust system

  • Through prop

Shallow water trim range (degrees)

  • 16

Remote fuel tank standard (gal / L)

  • 6.6 / 25

Color

  • Phantom Black

30 HP

HP / kW

  • 30 / 22.4

Engine type

  • Inline 3

Displacement (CID/CC)

  • 32.1 / 526

Full throttle RPM

  • 5250-6250

Fuel induction system

  • 2 valves per cylinder, single overhead cam (SOHC)

Alternator amp / Watt

  • 15 amp / 186 watt

Recommended fuel

  • Unleaded 90RON minimum

Recommended oil

  • Mercury FourStroke Oil 10W-30

Engine protection operator warning system

  • Low oil pressure

  • Over-rev

  • Overheat

  • Sensor failure

Starting

  • Electric (turn-key)

  • Manual

Steering

  • Remote

  • Tiller

Shaft length

  • 15" / 381 mm

  • 20" / 508 mm

Gearcase ratio

  • 1.92:1

Dry weight *Lightest model available

  • 78 kg

CARB star rating

  • 3

Bore and stroke

  • 2.40 x 2.36" / 61 x 60 mm

Ignition

  • CDI w/electronic spark advance

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim system

  • Gas assist

  • Power Trim

Exhaust system

  • Through prop

Shallow water trim range (degrees)

  • 16

Remote fuel tank standard (gal / L)

  • 6.6 / 25

Color

  • Phantom Black



40 - 60 HP FourStroke

SmartCraft Dijital Bilgi.

Yeni Mercury 40HP - 60HP EFI motorların gelişmiş SmartCraft yeteneği sayesinde tekne ve motor datalarını kapsamlı bir şekilde takip etme şansımız mevcuttur. Bu datalar trim, hız, devir, trol kontrolü, yakıt sarfiyatı gibi neredeyse tüm motor işlevleri için ve yakıt seviyesi, akü voltajı için tekne fonksiyonlarının zenginliği için detaylı motor durumu ve performans verisi sağlar. SmartCraft ayrıca, motor sensörlerini sürekli inceleyerek ve motorun tasarlandığı gibi çalışmayacağı durumları erken tespit ederek motorunuzu koruyan ve gerektiğinde düzeltici önlemi alan motor koruyuculuğu sağlar.

40 HP

HP / kW

  • 40 / 30

Engine type

  • Inline 4

Displacement (CID/CC)

  • 45.6 / 747

Full throttle RPM

  • 5500-6000

Fuel induction system

  • 2 valves per cylinder, single overhead cam (SOHC)

Alternator amp / Watt

  • 18 amp / 226 watt

Recommended fuel

  • Unleaded 90RON minimum

Recommended oil

  • Mercury FourStroke 25W40 Marine Oil

Engine protection operator warning system

  • SmartCraft Engine Guardian

Compatible with SmartCraft digital technology

  • Yes

Starting

  • Electric (turn-key)

Steering

  • Big Tiller Compatible

  • Remote

  • Tiller Kit

Shaft length

  • 20" / 508 mm

Gearcase ratio

  • 2.00:1

Dry weight *Lightest model available

  • 112 kg

CARB star rating

  • 3

Bore and stroke

  • 2.56 x 2.95" / 65 x 75 mm

Ignition

  • ECM 07 Digital Inductive (CT model)

  • ECM 70

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Command Thrust (CT)

  • Standard

Trim system

  • Power Trim

Exhaust system

  • Through prop

Shallow water trim range (degrees)

  • 20

Remote fuel tank (optional)

  • Yes

Color

  • Phantom Black

Lubrication system

  • Wet sump

50 HP

HP / kW

  • 50 / 37

Engine type

  • Inline 4

Displacement (CID/CC)

  • 60.8 / 995

Full throttle RPM

  • 5500-6000

Fuel induction system

  • 2 valves per cylinder, single overhead cam (SOHC)

Alternator amp / Watt

  • 18 amp / 226 watt

Recommended fuel

  • Unleaded 90RON minimum

Recommended oil

  • Mercury FourStroke 25W40 Marine Oil

Engine protection operator warning system

  • SmartCraft Engine Guardian

Compatible with SmartCraft digital technology

  • Yes

Starting

  • Electric (turn-key)

Steering

  • Big Tiller Compatible

  • Remote

  • Tiller Kit

Shaft length

  • 20" / 508 mm

Gearcase ratio

  • 1.83:1 or 2.33:1 (CT model)

Dry weight *Lightest model available

  • 112 kg

CARB star rating

  • 3

Bore and stroke

  • 2.56 x 2.95" / 65 x 75 mm

Ignition

  • ECM 07 Digital Inductive (CT model)

  • ECM 70

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Command Thrust (CT)

  • Standard

Trim system

  • Power Trim

Exhaust system

  • Through prop

Shallow water trim range (degrees)

  • 20

Remote fuel tank (optional)

  • Yes

Color

  • Phantom Black

Lubrication system

  • Wet sump

60 HP

HP / kW

  • 60 / 44.1

Engine type

  • Inline 4

Displacement (CID/CC)

  • 60.8 / 995

Full throttle RPM

  • 5500-6000

Fuel induction system

  • 2 valves per cylinder, single overhead cam (SOHC)

Alternator amp / Watt

  • 18 amp / 226 watt

Recommended fuel

  • Unleaded 90RON minimum

Recommended oil

  • Mercury FourStroke 25W40 Marine Oil

Engine protection operator warning system

  • SmartCraft Engine Guardian

Compatible with SmartCraft digital technology

  • Yes

Starting

  • Electric (turn-key)

Steering

  • Big Tiller Compatible

  • Remote

  • Tiller Kit

Shaft length

  • 20" / 508 mm

  • 25" / 635 mm (CT model)

Gearcase ratio

  • 1.83:1 or 2.33:1 (CT model)

Dry weight *Lightest model available

  • 112 kg

CARB star rating

  • 3

Bore and stroke

  • 2.56 x 2.95" / 65 x 75 mm

Ignition

  • ECM 07 Digital Inductive (CT model)

  • ECM 70

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Command Thrust (CT)

  • Standard

Trim system

  • Power Trim

Exhaust system

  • Through prop

Shallow water trim range (degrees)

  • 20

Remote fuel tank (optional)

  • Yes

Color

  • Phantom Black

Lubrication system

  • Wet sump



80 - 115 HP FourStroke

Yeni Nesil

Mercury'nin sektöre öncülük eden yenilikler sunma konusundaki hiç bitmeyen taahhüdü sayesinde, daha hafif ve daha kompakt dört zamanlı dıştan takmalı motor şimdi transomlarınız üzerinde, önceki 80 - 115 hp modellerine göre artan yakıt tasarrufu, sorunsuz bakım ve sağlam güvenirlik ile birlikte daha iyi performans, daha hızlı başlangıç ve çekiş kapasitesi sağlar.

80 HP

100 HP

HP / kW

100 / 74

Engine type

8-valve single overhead cam (SOHC)

Cylinder Configuration

Inline 4

Displacement (L)

2.1

Full throttle RPM

5000-6000

Air induction

Performance-Tuned Scroll Intake Manifold

Alternator amp / Watt

35 amp / 441 watt with water-cooled voltage regulator

Fuel induction system

Computer Controlled Multi-Port Electronic Fuel Injection (EFI)

Recommended fuel

Unleaded 90RON minimum

Recommended oil

Mercury FourStroke Oil 10W-30

Engine protection operator warning system

SmartCraft Engine Guardian

Compatible with SmartCraft digital technology

Yes

Starting

Smart Start Electric

Controls

Mechanical throttle & shift

Steering

Big Tiller Compatible, Dual cable mechanical, Hydraulic power steering

Shaft length

20" / 508 mm, 25" / 635 mm

Gearcase ratio

2.07:1

CARB star rating

3

Dry weight *Lightest model available

163 kg

Bore and stroke

3.5 x 3.2" / 90 x 81 mm

Ignition

SmartCraft ECM 70 Digital Inductive

Fuel system

Electronic Fuel Injection (EFI)

Cooling system

Water-cooled with thermostat

Gear shift

F-N-R

Gearcase options

Standard

Trim system

Power Tilt, Power Trim

Exhaust system

Through prop

Color

Phantom Black

Lubrication system

Wet sump

Oil Capacity

5.5 qts / 5.2 l

Maximum Tilt Range

70° (-6° to 64°)

Maximum Trim Range

22° (-6° to 16°)

HP / kW

100 / 74

Engine type

8-valve single overhead cam (SOHC)

Cylinder Configuration

Inline 4

Displacement (L)

2.1

Full throttle RPM

5000-6000

Air induction

Performance-Tuned Scroll Intake Manifold

Alternator amp / Watt

35 amp / 441 watt with water-cooled voltage regulator

Fuel induction system

Computer Controlled Multi-Port Electronic Fuel Injection (EFI)

Recommended fuel

Unleaded 90RON minimum

Recommended oil

Mercury FourStroke Oil 10W-30

Engine protection operator warning system

SmartCraft Engine Guardian

Compatible with SmartCraft digital technology

Yes

Starting

Smart Start Electric

Controls

Mechanical throttle & shift

Steering

Big Tiller Compatible, Dual cable mechanical, Hydraulic power steering

Shaft length

20" / 508 mm, 25" / 635 mm

Gearcase ratio

2.07:1

CARB star rating

3

Dry weight *Lightest model available

163 kg

Bore and stroke

3.5 x 3.2" / 90 x 81 mm

Ignition

SmartCraft ECM 70 Digital Inductive

Fuel system

Electronic Fuel Injection (EFI)

Cooling system

Water-cooled with thermostat

Gear shift

F-N-R

Gearcase options

Standard

Trim system

Power Tilt, Power Trim

Exhaust system

Through prop

Color

Phantom Black

Lubrication system

Wet sump

Oil Capacity

5.5 qts / 5.2 l

Maximum Tilt Range

70° (-6° to 64°)

Maximum Trim Range

22° (-6° to 16°)

115 HP

HP / kW

  • 115 / 84.6

Engine type

  • 8-valve single overhead cam (SOHC)

  • Inline 4

Displacement (L)

  • 2.1

Full throttle RPM

  • 5000-6000

Air induction

  • Performance-Tuned Scroll Intake Manifold

Fuel induction system

  • Computer Controlled Multi-Port Electronic Fuel Injection (EFI)

Alternator amp / Watt

  • 35 amp / 441 watt with water-cooled voltage regulator

Recommended fuel

  • Unleaded 91 RON Minimum

Recommended oil

  • Mercury FourStroke Oil 10W-30

Engine protection operator warning system

  • SmartCraft Engine Guardian

Compatible with SmartCraft digital technology

  • Yes

Starting

  • Smart Start Electric

Controls

  • Mechanical throttle & shift

Steering

  • Big Tiller Compatible

  • Dual cable mechanical

  • Hydraulic power steering

Shaft length

  • 20" / 508 mm

  • 25" / 635 mm

Gearcase ratio

  • 2.07:1

Dry weight *Lightest model available

  • 359 lbs / 163 kg

Emissions Star Rating

  • 3

Bore and stroke

  • 3.5 x 3.2" / 90 x 81 mm

Ignition

  • SmartCraft ECM 70 Digital Inductive

Fuel system

  • Electronic Fuel Injection (EFI)

Cooling system

  • Water-cooled with thermostat

Gear shift

  • F-N-R

Gearcase options

  • Standard

Trim system

  • Power Tilt

  • Power Trim

Exhaust system

  • Through prop

Shallow water trim range (degrees)

  • 20

Color

  • Phantom Black

Lubrication system

  • Wet sump

Oil Capacity

  • 5.5 qts / 5.2 l

Maximum Trim Range

  • 22° (-6° to 16°)

Maximum Tilt Range

  • 70° (-6° to 64°)
